SP1250XLE

The SP1250XLE is a full-featured on-line dual conversion UPS unit designed to meet the demands of critical and valuable cabinet equipment.

Space Saving Designed UPS

This model comes in a rack-mounted 1U form factor and feature Clary’s unique technology, which conditions utility power and protects against a broad range of power disturbances. The SP1250XLE is rated for 1250 VA / 875W and offers a compact and efficient solution for protecting your infrastructure.

PRODUCT SPECIFICATIONS

  • Voltage
    120 VAC ±3%

    Frequency
    50 Hz or 60 Hz

    Current
    10.4A

    Rating
    1250 VA / 875 W

    Crest Factor Ratio
    50% load up to 4.8:1, 75% load up to 3.2:1, 100% load up to 2.4:1

    THD
    3.00%

    Dynamic Response
    ±4% for 100% step load change 0.5 ms recovery time

    Overload
    110% for 10 sec; 200% for 50 ms

    UPS Protection
    Input and output short circuit, Input and output overload, Excessive battery discharge

  • Temperature
    -40°C to +74°C (-40°F to +165°F)

    Humidity
    0% to 95% non-condensing

    Altitude
    Sea level to 10,000 ft

  • Input
    IEC-320, C14 male connector

    Front Panel Input
    IEC-320, C14 male connector

    Front Panel Output
    IEC-320, C13 female receptacle

    Weight (lb)
    8

    Cooling
    Low velocity, Forced air

    Cabinet
    NEMA or 332 cabinet style configurations available

  • Standard Features
    Power factor corrected input, Fully regenerative, True on-line continuous power, Low distortion sine wave output, Designed for non-linear loads, Extended brownout protection, RS232 data interface

    Certifications
    FCC Class A, IEEE 587/ANSI C62.4, IEC 555 @ 120 VA, NEMA

    Typical Recharge Time
    (to 85% Capacity @ 100% Load)
    3 to 5 hrs (with extended battery option), 48-72 hrs (more time required with extended battery option)

  • Visual Indicators
    Load on

    Switches / Control Panel
    Four line LCD display panel
